The MH-Z19 is a low-cost NDIR CO₂ sensor, which means it measures carbon dioxide directly with infrared light rather than guessing at it like the cheap “eCO₂” parts. For a sealed greenhouse, a grow room, or a mushroom house, it is the budget route to a real CO₂ reading you can act on.
What it is.
The MH-Z19 (sold as the MH-Z19B and MH-Z19C) is a Winsen sensor that shines infrared light through a small tube of air and measures how much the CO₂ absorbs, the proven NDIR method. That is real CO₂ measurement, not the volatile-compound estimate the eCO₂ sensors make. It reports parts-per-million over a serial (UART) connection, and also as a PWM signal. It measures CO₂ only, with no temperature or humidity.
MH-Z19 or SCD40.
Both measure real CO₂; the choice is about format and budget. The MH-Z19 is cheaper and a known quantity, but it is a larger tube-style part, runs on 5 volts, talks over UART, and measures CO₂ only. The SCD40 is smaller, speaks the tidy I²C bus, throws in temperature and humidity, and is the more modern design, at a higher price. Pick the MH-Z19 to save money or when you already have a free serial port; pick the SCD40 for a compact I²C build that also wants climate.
Key facts.
Wiring and calibration.
Power it from 5 V (it needs the current to run its infrared lamp), and connect its TX and RX serial lines to a UART on your microcontroller (the data lines are 3.3 V-friendly). In ESPHome it has a dedicated MH-Z19 component on a UART bus. The same calibration caution as any NDIR sensor applies: it self-calibrates with an automatic baseline that assumes the room regularly returns to fresh-air CO₂. In a room you keep enriched, turn that auto-calibration off and calibrate manually, or its zero will drift.
Where it fits, and where it doesn’t.
Where it fits
- Real CO₂ on a budget for enrichment or ventilation.
- Builds with a free serial (UART) port and 5 V power.
- Greenhouses, grow rooms, and mushroom houses.
- Reading with an ESP32 and ESPHome.
Where it doesn’t
- Compact I²C builds; the SCD40 is smaller and adds climate.
- Temperature or humidity; it reads CO₂ only.
- An enriched room with auto-calibration left on.
- Life-safety alarms; use a certified monitor.
Resources & where to buy.
ESPHome: MH-Z19 Winsen MH-Z19B Where to buy CO₂ & air overview
Frequently asked questions.
Does the MH-Z19 measure real CO2?
Yes. It uses the non-dispersive infrared (NDIR) method to measure carbon dioxide directly, so its parts-per-million reading is real, unlike cheap eCO2 sensors that only estimate CO2 from other gases. It is the budget route to a true CO2 reading.
What is the difference between the MH-Z19 and the SCD40?
Both measure real CO2. The MH-Z19 is cheaper, larger, runs on 5 volts, talks over UART, and reads CO2 only. The SCD40 is smaller, uses I2C, also reports temperature and humidity, and is more modern, at a higher price. Choose by budget and build format.
How do I connect an MH-Z19 to an ESP32?
Power it from 5 volts and wire its TX and RX serial lines to a UART on the ESP32. In ESPHome, configure a UART bus and the MH-Z19 component, and the CO2 reading appears in Home Assistant. The data lines work at 3.3 volts.
Why does my MH-Z19 reading drift over time?
Its automatic baseline calibration assumes the room regularly reaches fresh-air CO2 levels. In a room kept enriched above outdoor CO2, that assumption is wrong and the zero drifts. Turn the automatic baseline off and calibrate manually for enriched spaces.
